At The Dials
January 17th, 2018 |
Author:  |
| Courtesy |
A recent never-ending series of equipment breakdowns, repairs, computer software problems, along with everyday household duties, has kept me away from blogging longer than usual.
However, the recent arrival of a fresh 'off the press' 2018 World Radio Television Handbook (WRTH) has really augmented my rekindled interest in what initially hooked me on the magic of radio ... tuning around the international shortwave bands.
The last time I purchased a WRTH was more than 40 years ago, but other than the information between its covers, the book still looks much the same as it did back in the good old days. There is a lot to digest in this book and although it's likely that a lot of it could be found on the Internet, it would probably take weeks of sleuthing to find it ... there is just a ton of valuable information here to accommodate the varied interests of radio fanatics.
As always, the first section of the book is devoted to technical articles or equipment reviews with the remainder being a quick-find reference guide of maps, frequency lists, broadcast schedules and mailing / e-mail contact info for those that like to gather QSLs. At 672 pages, the WRTH is a valuable tool in your listening arsenal and well worth the cost.I often read comments on various reflectors of just how few international shortwave stations there are and that tuning through the bands often reveals little to be heard. There is no question that the number of SW stations on the air today is much less than it was a few decades ago, but there are still a huge number of stations to target throughout the various SW bands and a lot of DX challenges yet to be found on the international bands.
For example, one such challenge comes to mind for west coast DXers ... and that is India. Signals on any band, from India to western Canada, have always been difficult. All India Radio (AIR) has 22 shortwave transmitters, operating from a half-dozen different sites ... hearing all sites from here on the various bands would keep one pretty busy for some time. To make it even more interesting, AIR still responds to listener reception reports with a QSL ... and who doesn't like a real 'paper' QSL!
Here is a quick tune through the 31m SW band this morning, at around 10:20 a.m. local time, on my FT-1000mp Mark V and 40m half-sloper. Although approaching the lowest part of a very poor solar cycle (Cycle 24, the weakest in the past 100 years), witness the activity on a day of very poor HF propagation ... there are still a good number of signals to seek out.
With the present low solar flux, it's usually the lower SW bands that really come to life, with the bands bursting with signals from shortly before sunset into the dawn.
In addition to the WRTH, there are several great reference sites on the internet as well as some wonderfully helpful blogs devoted to SW radio listening.
Here are the sites I find myself returning to quite often:
Yahoo Group's Primetimeshortwave
Worldwide DX Club News
Eibi Shortwave Time / Frequency Schedules
Shortwave Info
Hard-Core-DX Daily News
Blogs:
Mount Eveyln DX Report
The SWLing Post
Bulgarian DX Blog
South East Asia DXing
There are probably more but these ones are good. In addition, there are a lot of great Facebook sites that deal with SW radio and much interesting discussion is available there via a quick search.
Now it's back to the repair bench to hopefully finish everything off for some time, but maybe you can find a few spare hours to have a closer listen to the international SW bands and see what you can dig up.
SHORTWAVE BROADCAST BANDS
2300 - 2495 120m
3200 - 3400 90m
3900 - 4000 75m
4750 - 5060 60m
5850 - 6200 49m
7100 - 7350 41m
9400 - 9900 31m
11600 - 12050 25m
13570 - 13800 22m
15100 - 15800 19m
17480 - 17900 16m
18900 - 19020 15m
21450 - 21850 13m
25600 - 26100 11m
Rest in Peace, David Collingham, K3LP, SK
RIP David Collingham, SK – K3LP is now SK.
My condolences to the family and friends, and to our radio community, for the tragic loss of David Collingham, K3LP.
I am sad and sorry for his loved ones and friends who now grieve this loss.
May his memory echo through the ether like radio waves, reaching the receivers of our hearts.
Passing along a note from Paul, N6PSE:
Dear Friends of David Collingham-K3LP:
I have learned additional information concerning his death.
Last night, during a heavy winter storm, David let his dog outside. David later took his truck to search his 25-acre property when his dog did not return. David found that his dog had fallen into an icy pond that adjoins his property with another property.
David made the heroic decision to go into the pond to try and save his dog.
After some time had passed, David’s wife Rebecca went looking for him. She found his truck at the pond and called 911. Fire personal recovered David’s body as well as his dog. Efforts to resuscitate him were unsuccessful.
David lived his life bold, courageous and heroically and he died trying to save his beloved dog. He will always be a hero in our hearts.
RIP David R. Collingham, age 59.
A 630m Maritime Adventure
 |
| HAKUNA MATATA |
Crewed by Mark (VA7MM) and YL May (VE7MAY), Toby (VE7CNF) and XYL Nancy, the 31' Benateu recently completed a 14-day circumnavigation of Georgia Strait's Gulf Islands. This is a yearly adventure that has been successfully completed for the past few summers and looks as though it may now be an annual tradition.
Normally, the crew kept up regular radio contact on HF as well as on VHF when possible but this year saw a major departure.
In previous summers, near the end of the voyage, the crew has always visited us here on Mayne Island for an afternoon of vittles and libation before heading for home. There is always a good amount of time spent recalling the past-year's radio activities, winter projects and reminiscence of the 'good old days'. Last year, just as the party was ending, I jokingly suggested that 'next year', it would be cool to work them from the boat on 630m.
Although there was no immediate commitment, I knew that the seed had been planted, and with three of the four crew being engineers, I suspected it might be hard for them to resist, and ... just before departure, the local bunch of 630m ops were put on alert to be watching for CF7MM/mm on 475 kHz CW as they would be attempting to work us from three different overnight anchorages during their summer voyage!
Evidently Toby had been working quietly during the winter to make this become a reality. Here are some pictures of the system along with Toby's (the system's builder) comments.
 |
| Variometer and matching transformer |
 |
| Wire vertical and loading coil |
 |
| Toby (VE7CNF) working the pileups! |
 |
| Tuneup |
QSOs were made at anchor from Boho Bay (49 29.808N 124 13.857W near Lasqueti Is), Silva Bay (49 09.047N 123 41.670W near Gabriola Is), and Winter Cove (48 48.621N 123 11.575W near Saturna Is).
 |
| The route, heading north from Vancouver |
Stations worked on CW were VE7SL (Steve on Mayne Is, 12 to 48W TPO), VE7BDQ (John in Delta, 4 to 25W TPO), VE7VV (Roger in Victoria, 10W TPO), VE7CA (Markus in North Vancouver, 70W TPO), VA7JX (Jack in Campbell River, 100W TPO). Both VE7SL and VE7VV were also worked using LSB phone from Winter Cove.
Some of the contacts are shown below. Note the transceiver is not really on 160m ... it's just the i.f. for my 630m transverter!
Some of the contacts are shown below. Note the transceiver is not really on 160m ... it's just the i.f. for my 630m transverter!
I was impressed with the strength of ground wave signals given the low transmitter powers and EIRP's well below 5W. Received signals ranged from S1 to S9+10dB and copy was easy for all QSOs. QSO distances ranged from 10 to 142 km. We had low receive noise levels in all locations, with Silva Bay being a little noisier than the others due to many nearby boats and some shore power lines.
We tried disconnecting the gunnel ground wires and leaving only the keel, and found that the antenna capacitance and resistance did not change. When we disconnected the keel and left only the gunnel wires, the antenna capacitance dropped to about 87pF and antenna resistance dropped by a few ohms. It appears that the keel provided most of our ground coupling to sea water and it would have been a sufficient ground on its own.
It would have been interesting to compare signal reports with different ground arrangements. Next time...
More details of Toby's 630m transverter as well as a practical 630m antenna tune-up procedure can be found on his website here.
All-in-all, I think the 630m operation was a great success and very likely the first-ever 630m marine mobile operation on that band, as I don't recall this happening anywhere else over the years. It was also a great way to pay homage to the band's original maritime heritage where its quality groundwave and skywave capabilities were used to advantage for so many decades safeguarding mariners worldwide.
Maritime mobile operation on the amateur bands has some great history behind it, including the yacht YASME. In the mid-50's, Danny Weil was the first ever amateur to undertake DX'pedition style operations via sailboat, as he visited numerous rare islands in the Caribbean and South Pacific.
 |
| Danny on the YASME - courtesy: www.gm3itn.co.uk |
 |
| Original YASME QSL - courtesy: http://hamgallery.com/ |
His exploits were regularly published in CQ magazine at the time and always made for exciting reading as Danny would eventually wreck three YASMES over the years! His adventures laid the groundwork for future island-hopping DX operations such as those undertaken by Gus Browning (W4BPD), Don Miller (W9WNV) and all that followed ... I'm sure they would all have enjoyed working the HAKUNA MATATA as well!
A 630m Maritime Adventure
|
| HAKUNA MATATA |
Crewed by Mark (VA7MM) and YL May (VA7MAY), Toby (VE7CNF) and XYL Nancy, the 31' Benateu recently completed a 14-day circumnavigation of Georgia Strait's Gulf Islands. This is a yearly adventure that has been successfully completed for the past few summers and looks as though it may now be an annual tradition.
Normally, the crew kept up regular radio contact on HF as well as on VHF when possible but this year saw a major departure.
In previous summers, near the end of the voyage, the crew has always visited us here on Mayne Island for an afternoon of vittles and libation before heading for home. There is always a good amount of time spent recalling the past-year's radio activities, winter projects and reminiscence of the 'good old days'. Last year, just as the party was ending, I jokingly suggested that 'next year', it would be cool to work them from the boat on 630m.
Although there was no immediate commitment, I knew that the seed had been planted, and with three of the four crew being engineers, I suspected it might be hard for them to resist, and ... just before departure, the local bunch of 630m ops were put on alert to be watching for CF7MM/mm on 475 kHz CW as they would be attempting to work us from three different overnight anchorages during their summer voyage!
Evidently Toby had been working quietly during the winter to make this become a reality. Here are some pictures of the system along with Toby's (the system's builder) comments.
|
| Variometer and matching transformer |
|
| Wire vertical and loading coil |
|
| Toby (VE7CNF) working the pileups! |
|
| Tuneup |
QSOs were made at anchor from Boho Bay (49 29.808N 124 13.857W near Lasqueti Is), Silva Bay (49 09.047N 123 41.670W near Gabriola Is), and Winter Cove (48 48.621N 123 11.575W near Saturna Is).
|
| The route, heading north from Vancouver |
Stations worked on CW were VE7SL (Steve on Mayne Is, 12 to 48W TPO), VE7BDQ (John in Delta, 4 to 25W TPO), VE7VV (Roger in Victoria, 10W TPO), VE7CA (Markus in North Vancouver, 70W TPO), VA7JX (Jack in Campbell River, 100W TPO). Both VE7SL and VE7VV were also worked using LSB phone from Winter Cove.
Some of the contacts are shown below. Note the transceiver is not really on 160m ... it's just the i.f. for my 630m transverter!
Some of the contacts are shown below. Note the transceiver is not really on 160m ... it's just the i.f. for my 630m transverter!
I was impressed with the strength of ground wave signals given the low transmitter powers and EIRP's well below 5W. Received signals ranged from S1 to S9+10dB and copy was easy for all QSOs. QSO distances ranged from 10 to 142 km. We had low receive noise levels in all locations, with Silva Bay being a little noisier than the others due to many nearby boats and some shore power lines.
We tried disconnecting the gunnel ground wires and leaving only the keel, and found that the antenna capacitance and resistance did not change. When we disconnected the keel and left only the gunnel wires, the antenna capacitance dropped to about 87pF and antenna resistance dropped by a few ohms. It appears that the keel provided most of our ground coupling to sea water and it would have been a sufficient ground on its own.
It would have been interesting to compare signal reports with different ground arrangements. Next time...
More details of Toby's 630m transverter as well as a practical 630m antenna tune-up procedure can be found on his website here.
All-in-all, I think the 630m operation was a great success and very likely the first-ever 630m marine mobile operation on that band, as I don't recall this happening anywhere else over the years. It was also a great way to pay homage to the band's original maritime heritage where its quality groundwave and skywave capabilities were used to advantage for so many decades safeguarding mariners worldwide.
Maritime mobile operation on the amateur bands has some great history behind it, including the yacht YASME. In the mid-50's, Danny Weil was the first ever amateur to undertake DX'pedition style operations via sailboat, as he visited numerous rare islands in the Caribbean and South Pacific.
|
| Danny on the YASME - courtesy: www.gm3itn.co.uk |
|
| Original YASME QSL - courtesy: http://hamgallery.com/ |
His exploits were regularly published in CQ magazine at the time and always made for exciting reading as Danny would eventually wreck three YASMES over the years! His adventures laid the groundwork for future island-hopping DX operations such as those undertaken by Gus Browning (W4BPD), Don Miller (W9WNV) and all that followed ... I'm sure they would all have enjoyed working the HAKUNA MATATA as well!
The VK3BVW Winter DX Survey
 |
| courtesy: VK3BVW |
Every once in awhile I get the yen to tune through the international SW broadcast bands as my interest in good old, basic SWL'ing, is rekindled.
These bands are certainly quieter compared to when I first discovered the magic of radio and started DXing at age eleven using a lovely old all band cathedral-style GE set up in my attic-high radio shack ... no longer just a boring attic bedroom, but one with walls plastered with QSLs from all over the world.
It was an amazing experience and one that obviously has left a lasting impression. There were hundreds and hundreds of stations on SW, throughout all of the HF bands but the highest I could tune was 19mc. on the old General Electric beauty ... who knows what was missed up higher as this was the peak of Cycle 19 and HF was on fire!As the huge decline in international SW broadcasting over the past few years continues, I'm always pleasantly surprised to see that there are still a lot of nice DX targets to hunt for.
I was particularly excited to read Rob's (VK3BVW) just released blogspot, describing his fall listening project from down-under. Being the DX season down in Australia, Rob decided to do daily bandscans of the low HF international SW bands (4.8 - 10MHz) to see what popped-up from day to day, which was actually afternoon to afternoon, since his listening was done between noon and 4PM local time. The project may be viewed here along with a nice introductory video ... in all, a huge effort by Rob with a lot of helpful details to go along with the logs.
While there be sure to visit the rest of Rob's SW blog ... there's a lot of good stuff here to get your SWL juices flowing!
His survey results are very encouraging for those of us that may have thought that there is just not much to be heard when it comes to international SW broadcasting. As Rob points out, even though these logs reflect what was heard in Australia, most, if not all should be hearable in North America as well, even more so as we approach the DX season in North America.
So pull up your chair sometime after dark, grab a cup of your favorite beverage, and take a relaxing tune through the SW bands with Rob's list in hand ... see what you can find, and perhaps rekindle that early fascination in SW radio outside of the ham bands that may have hooked you many years ago. You may also find this broadcast frequency database helpful should you run across something unknown.
The VK3BVW Winter DX Survey
|
| courtesy: VK3BVW |
Every once in awhile I get the yen to tune through the international SW broadcast bands as my interest in good old, basic SWL'ing, is rekindled.
These bands are certainly quieter compared to when I first discovered the magic of radio and started DXing at age eleven using a lovely old all band cathedral-style GE set up in my attic-high radio shack ... no longer just a boring attic bedroom, but one with walls plastered with QSLs from all over the world.
It was an amazing experience and one that obviously has left a lasting impression. There were hundreds and hundreds of stations on SW, throughout all of the HF bands but the highest I could tune was 19mc. on the old General Electric beauty ... who knows what was missed up higher as this was the peak of Cycle 19 and HF was on fire!As the huge decline in international SW broadcasting over the past few years continues, I'm always pleasantly surprised to see that there are still a lot of nice DX targets to hunt for.
I was particularly excited to read Rob's (VK3BVW) just released blogspot, describing his fall listening project from down-under. Being the DX season down in Australia, Rob decided to do daily bandscans of the low HF international SW bands (4.8 - 10MHz) to see what popped-up from day to day, which was actually afternoon to afternoon, since his listening was done between noon and 4PM local time. The project may be viewed here along with a nice introductory video ... in all, a huge effort by Rob with a lot of helpful details to go along with the logs.
While there be sure to visit the rest of Rob's SW blog ... there's a lot of good stuff here to get your SWL juices flowing!
His survey results are very encouraging for those of us that may have thought that there is just not much to be heard when it comes to international SW broadcasting. As Rob points out, even though these logs reflect what was heard in Australia, most, if not all should be hearable in North America as well, even more so as we approach the DX season in North America.
So pull up your chair sometime after dark, grab a cup of your favorite beverage, and take a relaxing tune through the SW bands with Rob's list in hand ... see what you can find, and perhaps rekindle that early fascination in SW radio outside of the ham bands that may have hooked you many years ago. You may also find this broadcast frequency database helpful should you run across something unknown.
Calling Olivia-mode Operators (from All Regions)
Calling all Olivia-mode operators with experience using the Olivia digital mode in all areas of the world:
Please join our Facebook group at the following link. We are discussing important operational changes!
If you are on Facebook, and interested in the Olivia HF radioteletype chat mode, please join the community group at the following link: https://www.facebook.com/groups/olivia.hf/
If you want to join our discussion by way of the Olivia group on Groups.io, please feel free to spread the news, and also to subscribe to that group email reflector. We’ll start discussions, soon. Here’s the link: https://groups.io/g/Olivia
OLIVIA (Also, Olivia MFSK) is an amateur digital radioteletype mode designed by Pawel Jalocha, SP9VRC, starting in 2003, and in use by 2005. The Olivia-mode goal was to be effective even in poor propagation conditions on the high frequencies (shortwave).
OLIVIA can decode well under noise, propagational fading (QSB), interference (QRM), flutter caused by polar path propagation and even auroral conditions and sporadic-E. Olivia uses a 7-bit ASCII alphabet. There were a handful of amateur digital modes that were derived from Olivia, including RTTYM and PAX.
Outside of amateur radio two-way communication, this mode is utilized during the tests run by the VoA every weekend. See the VoA RadioGram website, VoARadiogram.net, for the schedule.
The Olivia QSO between K4SOL and NW7US using 16/500 mode settings on shortwave, 2017-AUG-06 @1410UTC
The first on-the-air tests were performed by two radio amateurs, Fred OH/DK4ZC and Les VK2DSG on the Europe-Australia path in the 20-meter amateur band. The tests proved that the protocol works well and can allow regular intercontinental radio contacts with as little as one watt RF power. Since 2005 Olivia has become a standard for digital data transfer under white noise, fading and multipath, flutter (polar path) and auroral conditions.
Voluntary channelization
Since Olivia signals can be decoded even when received signals are extremely weak, (signal to noise ratio of -14 dB), signals strong enough to be decoded are sometimes below the noise floor and therefore impossible to search for manually.
As a result, amateur radio operators have voluntarily decided upon channelization for this mode. This channelization allows even imperceptibly weak signals to be properly tuned for reception and decoding. By common convention amateur stations initiate contacts utilizing either the 16/500 or 32/1000 modes and then switch to other modes to continue the conversation. The following table lists the common center frequencies used in the amateur radio bands.
The traditional channels are now under heavy use by newer modes. Thus, this Olivia group is working on refiguring the strategy for continued use and channelization. Please join us for discussion.
https://www.facebook.com/groups/olivia.hf/
[embedyt]https://www.youtube.com/watch?v=g-EXniWF79w[/embedyt]
[embedyt]https://www.youtube.com/watch?v=FUjiBVsXrzE[/embedyt]
[embedyt]https://www.youtube.com/watch?v=Yz7a–ePSNs[/embedyt]
Thank you,
Tomas / NW7US
