Last night I uploaded HamRadioNow Episode 138. I’m calling it MotoTRBOStar because it’s about a newly announced handheld radio that will claim some firsts: it’s the first “dual-digital” mode radio (D-STAR; and MOTOTRBO, or generically DMR – Digital Mobile Radio); and it’s the first non-ICOM off-the-shelf radio to do D-STAR.* The episode is an interview with the CEO of Connect Systems, Inc., Jerry Wanger (rhymes with Ranger). CSI (isn’t that a TV show?) has been selling analog, trunked and DMR digital handheld radios in the commercial service. Recently, Jerry learned that a lot of hams have latched onto his radios for use on the ham-band MOTOTRBO repeaters. The radios are quite inexpensive, and apparently pretty high quality.

Jerry had a novice license long ago, but never mastered the code to upgrade. Side note: back in the 60’s, a Novice license ran one year and couldn’t be renewed.  And Novices had voice privileges on only one band: two meters. So Novices who spent too much time on two-meter AM (there was almost no FM then) and didn’t get their code speed up to 13 wpm for a General could get a Tech, but then they were confined to VHF/UHF. Again, repeaters were just barely getting started and were mostly unknown, so Techs were in a kind of Purgatory. But it was a way to keep licensed. Evidently Jerry didn’t choose that route. But he’s about to get re-licensed now.

So Jerry appreciates ham radio, and decided to make a model radio (CS700) that was more “ham-friendly,” with features like DTMF and the ability to program frequencies and parameters directly from the keypad. Then he decided to add D-STAR. That model, the CS7000, is planned for Fall release. He’ll be at Dayton to show it off.

Jerry does the software and designs the hardware specs himself, and has the radios manufactured in China. As he says, he can buy the finished radios cheaper than he can buy the parts.

So that’s all in the interview. Now I’ll wax a bit philosophical on the topic.

I’ve been a ham since 1965, WN9NSO, in the Chicago suburbs. And while I did play on two meter AM with a Heathkit Twoer (to the displeasure of my mentors, who warned sternly about neglecting the code), I also spent enough time in the 40 and 15 meter Novice cw bands to wick the speed up and pass my General after just a few months. And while I have almost always had a presence on HF, I’ve felt more at home on VHF/UHF. I was introduced to FM almost immediately. I had a Motorola 30D base station in my shack, and 80D mobile in my Dad’s car by 1967 (these were ancient, all-tube radios. The 80D even had a Dynamotor to power the transmitter). There were only two or three repeaters on the air in Chicago at the time. I was too young (and never an engineer) to be much of a leader at the time, but I watched the FM boom from a front row seat.

Fast forward to the early 2000’s. I’m editor of the SERA Repeater Journal, the magazine published by the SouthEastern Repeater Association, the group that does frequency coordination for 8 states. I come across a reference to D-STAR, and while I didn’t think much about it at the time, I did ponder a digital future in my column. But D-STAR wasn’t one of those flights of fancy that came and went. With ICOM behind it, D-STAR grew beyond it’s original 1200 MHz system as ICOM added radios for 144 and 440 MHz. Meanwhile, I had moved from editing the magazine to producing ham radio video on DVD as ARVN:Amateur Radio//Video News. I bought ICOM’s first D-STAR dual-band mobile, the ID-800, and handheld, the IC-91, and soon after produced a documentary titled Digital Voice for Amateur Radio. The DVD also featured a segment on HF digital voice, and a little on APCO-25, another VHF/UHF digital mode being adapted from Public Safety radio to Amateur Radio. I’ve written a few articles and reviews in QST on D-STAR and ICOM radios. I’m not the foremost authority on it by any means – I consider myself a journalist (with a side of pundit these days), not an expert – but I’ve learned a lot. And ham radio doesn’t have many pure journalists. Everybody’s involved.

D-STAR was met by hams with sharply divided reaction (and more than a few yawns). A few embraced it immediately (best thing ever). A few more were rigidly opposed (End Of Amateur Radio As We Know It). Most, if they were even aware of it in the early years, were more wait-and-see. Not gonna sink a lot of money into a radio that might not go anywhere. All the D-STAR radios were good Analog radios, too, but they were a few hundred bucks more expensive, so while the radio wouldn’t be useless, it would have been a costly experiment.

Turns out D-STAR has hung around and grown fairly quickly. It’s in most major and medium metro areas, and even some rural areas, of the US and many countries around the world. But there’s still plenty of territory that has had analog FM for decades but no D-STAR at all yet. Any long road trip will quickly bear that out. You’ll drive a long way between “islands” of D-STAR coverage. It’s very much like FM was in 1970 – available mostly in the larger cities. I remember being excited when driving toward Denver way back then. A mountainside repeater on 146.94 broke my squelch about 100 miles out after hours and hours of radio silence.

D-STAR proponents, and even us “objective journalists” (OK, I’m not objective on this) point out how much technology is going digital (TV, cell phones, a fair amount of two-way business and Public Safety radio) while hams have barely moved the needle, except for the all-text modes. Yeah, we led the way with Packet Radio in the 80’s (a few did, anyway… not most of us). But for a group that likes to talk more than anything else, our voices have remained mostly analog, right up to today. Digital has some advantages (signal to noise, voice+data, and spectrum efficiency), but they haven’t been compelling enough yet to get wholesale adoption. Except for D-STAR, they mostly haven’t been built-in to radios. And on HF especially, we don’t know how we’d use them for some of the core activities like contests and DX.

As we gaze outside of our pasture to that real world that’s growing increasingly digital, there’s another issue to note. Digital doesn’t stand still very long. Upgrades happen fast, and sometimes older stuff becomes obsolete – even unusable – pretty quickly. Analog TV made it about 60 years. Vinyl records a little longer. CDs aren’t dead, but sales went to nearly zilch, after about 20 years. On the Internet, where software and apps can be easily upgraded or replaced, we’re talking a few years or even months. Remember “RealTV”? And you know that 70″ 1080p High-Def TV you just got. Obsloete. Here comes 4k. Then 8k. Broadcast TV stations are going nuts trying to figure out to squeeze that into their “Advanced” television system. **

I’m about to edit my next HamRadioNow that I recorded yesterday with Bruce Perens K6BP. Bruce is a serious open-source guy, so he never had a great love for D-STAR. Bear that in mind when he declares it obsolete. Objectively, things in ham radio move slower. Whenever there’s fixed hardware involved, upgrades can’t happen that fast – it costs too much. But D-STAR is 15 years old, and better technology is available. Yaesu claims their new C4FM “System Fusion” is “better.” Bruce disputes that, and I don’t have the background to determine it for myself. But I can say that if Yaesu is correct now, what can they say in 5 years (0r 5 months) when the next something better comes along?

Bruce is involved in a couple of projects. For HF, there’s FreeDV, and for VHF/UHF, it’s the “HT of the Future.” Both are based on the open-source CODEC2, which is still very much under development, and always will be, at least for the foreseeable future. Today, FreeDV is a sound-card mode that you can run much like PSK-31. Tomorrow, you might punch it up on the mode switch (Flex will probably be the first radio to have that option). FreeDV – and probably a lot of new modes – will be upgradable by downloading software. I won’t say it will never be obsolete, but it’s the kind of thing that will move us from being slow-moving dinosaurs tied to our fixed-technology hardware, into a more nimble future where we are not walled off from each other by incompatible modes. All this stuff is coming up in HamRadioNow Episode 139, as soon as I can stop typing here and get back to editing it (maybe tomorrow or Monday).

Ya know… I’ve never operated FreeDV or it’s predecessors (FDMDV, WinDRM) that I featured in Digital Voice for Amateur Radio. I don’t have a computer sitting next to my HF rig… at least not yet. All my computers are busy doing something else. But I’ll find one soon, and give it a try.

73, Gary KN4AQ

* Devices like the DVDongle are cool, but they’re not standalone radios. There are a few modules that you can use to turn an analog radio into a D-STAR radio using its 9600 packet port, but that’s not off-the-shelf. The NW Digital radio might lay claim to being the first non-ICOM commercial D-STAR capable radio if it reaches production before the CS-7000 does, and right now it’s a race. But while it will do D-STAR’s DV voice mode, it’s really designed as a multi-mode platform for medium-speed data, using D-STAR’s DD mode and many others. It will have exciting uses, but it’s not your grab-and-go handheld or mobile radio.

** My career has been in the audio/video production business, mostly making commercials. I quickly learned a lesson: never stick a label on anything that calls it “new.” And never call anything “final.” OK, sort of two lessons.

The “new” lesson came from a reel of alignment videotape that we used at a TV station I worked for. You had to run that through the old 2″ “Quad” videotape machines to align the heads before making a recording, so the reel got used several times a day. It started life as a 5-minute piece of tape, but every time you used it, you’d then rewind it and thread a piece of blank tape for recording onto the machine. That rewind was high-speed, and if you didn’t catch it fast enough, the end of the tape would flap like crazy, and get frayed. You had to cut the frayed piece off lest it get caught in the high-speed spinning video heads next time, clogging the hell out of them and maybe ruining a head assembly that cost tens of thousands of dollars to replace. The boss would be very angry.

When I started working at the station, that alignment reel had about 45 seconds of tape left on it, having had a half-inch of frayed end cut off many, many times. And the flange was grimey from all the hands that had loaded it on the machines over the years. But there beneath the grime, just barely readable in faded Sharpie, were the words that some engineer wrote just after he took that reel out of the box for the first time: Alignment Tape. 5 min. NEW.

Solar Flare Alert:

Active Sunspot Region 11944 has a 75% chance of producing an M-class flare, and a 30% chance of producing an X-class flare, in the next 24 hours. Smaller flares are also possible.

We are expecting a glancing blow from a Coronal Mass Ejection (CME) sometime in the next 24 hours.

The Earth’s polar regions are under a proton event (Polar Cap Absorption, or PCA, event). This is degrading HF communications over polar regions.

(Live data and more info at https://Facebook.com/spacewx.hfradio or http://SunSpotWatch.com/ )

While many are talking about how Solar Cycle 24 is the weakest since the Maunder Minimum (the period starting in about 1645 and continuing to about 1715 when sunspots became exceedingly rare, as noted by solar observers of the time — see this Wiki entry), there are moments when activity on the Sun strongly increases, providing brief moments of excitement.

Here is a case in point, witnessed by the Solar Dynamics Observatory (SDO; see SDO Mission) on June 7, 2011, when the Sun unleashed a magnitude M2 (a medium-sized) solar flare with a spectacular coronal mass ejection (CME). The large cloud of particles mushroomed up and fell back down looking as if it covered an area almost half the solar surface.

SDO observed the flare’s peak at 1:41 AM ET. SDO recorded these images in extreme ultraviolet light that show a very large eruption of cool gas. It is somewhat unique because at many places in the eruption there seems to be even cooler material — at temperatures less than 80,000 K.

This video uses the full-resolution 4096 x 4096 pixel images at a one minute time cadence to provide the highest quality, finest detail version possible.  The color is artificial, as the actual images are capturing Extreme Ultraviolet light.

It is interesting to compare the event in different wavelengths because they each see different temperatures of plasma.

Credit: NASA SDO / Goddard Space Flight Center

Video: http://g.nw7us.us/1aOjmgA – Massive Solar Eruption Close-up (2011-06-07 – NASA SDO)

Visit: SunSpotWatch.com

“Radio Hams” do more than play with their machines. They are also invaluable in relaying vital information during times of tragedy and disaster.

Here is a mildly entertaining look at radio hams, those amateurs sending and receiving coded messages during the late thirties when films first dealt with the subject of “radio hams.” In this case, the ham operators manage to be helpful during situations of stress, using their abilities with code to help someone in distress and to seek aid for pilots flying a missing plane.

The humorous ending has the family gathered around the radio listening to someone speaking Chinese while the narrator tells us how impressed the family was to be hearing someone across the world on their radio set.

http://www.youtube.com/watch?v=bZi7LiPNMt8

This little vintage film, a rather more serious film than many of Pete Smith’s other presentations, takes a look at how ham radios can become priceless aids during emergencies. The two stories shown, one dealing with sickness, the other with a missing plane, are bookended by a humorous look at a typical three-generation family’s fascination with their ham radio.

Of course, amateur radio, or “ham radio”, is alive and doing very well, in our modern times. Using satellites, moon-bounce communications, repeater networks, as well as shortwave, mediumwave, and longwave telecommunications technology, amateur radio continues to provide emergency services in times of need, from hurricanes, tornadoes, earthquakes, and even during such times as the infamous 9/11 atrocity. But, amateur radio also breeds invention and experimentation, always at the cutting edge of science. It is a hobby worth investigating, having room for a wide-range of interests. Preppers, science lovers, experimenters, and those with a passion to meet people from all over the world by way of radio waves, all together make up the radio hobby of amateur radio.

Clayton Moore, later famous as the Lone Ranger, appears uncredited as a ship radio operator.

Directed by Felix E. Feist

Writing Credits Buddy Adler (screenplay) (as E. Maurice Adler)

Cast (in alphabetical order)

Barbara Bedford – Mrs. Crane (uncredited)
Eleanor Counts – Miss Mulligan, Jimmy’s Sister (uncredited)
Jack Daley – Pa Mulligan (uncredited)
Robert Homans – Lighthouse Keeper (uncredited)
Clayton Moore – Ship Radio Operator (uncredited)
Alonzo Price – Clyde DeVinna (uncredited)
Jason Robards Sr. – Pilot in Distress (uncredited)
Pete Smith – Narrator (voice) (uncredited)
Harry Strang – Man in Montage (uncredited)
Phillip Terry – Co-Pilot (uncredited)
Dorothy Vaughan – Ma Mulligan (uncredited)

Produced by Pete Smith – producer (uncredited)
Music by David Snell (uncredited)
Cinematography by Robert Pittack
Film Editing by Philip W. Anderson (as Philip Anderson)
Music Department Jack Virgil – orchestrator (uncredited)
Other crew Douglas Smith – technical advisor

According to https://archive.org/details/wwIIarchive this film is in the Public Domain.
Creative Commons copyright.

The Sun currently is active, with powerful, complex magnetic structures that have formed a healthy number of sunspots. We are seeing a fair number of x-ray flares, which push the 10.7-cm flux higher than we’ve seen in a while.

Sunspots and flares means better propagation in general, especially on the higher frequencies of the shortwave spectrum.  While a flare can cause a short period of “blackout” conditions (especially on the lower frequencies) on the sunlit side of the Earth, such activity is part of the positive activity that ionizes the F-region, providing for DX.

Here’s a movie of one such flare and the release of solar plasma, a release known as a coronal mass ejection (CME): At about midnight, UTC, on 6 November 2013, a moderately-strong M-class flare erupted, with a “beautiful” CME: http://g.nw7us.us/18a0QvI

(Source: SOHO/SDO/NASA)

We will see continued flare activity over the weekend, so expect great conditions on the HF bands, with momentary blackouts.  Keep up to the minute on space weather at http://SunSpotWatch.com

73 – de NW7US
Propagation Columnist, CQ Communications Magazine, Popular Communications Magazine
http://NW7US.us

New sunspot region, NOAA Active Sunspot Region Nr. 11890, far left on the solar disc, will produce flares, this week.

The Sun continues to produce sunspots, and this week looks active, too.  Expect another uptick of activity on higher HF bands such as 10 meters, as a “new” sunspot region has now rotated into full view.  It has a complex magnetic structure, so it could produce moderate and maybe strong x-ray flares.  We expect flaring activity to pick up, as a result.

With all of the recent activity, and the continued train of spots, right now, it certainly appears to be a sign of a “second” peak in the cycle.  Most cycles exhibit such double peaks.  Is this one of them in this current Sunspot Cycle 24?

Enjoy the DX!

73 de NW7US (Your CQ Magazine and Popular Communications Magazine propagation columnist)

http://SunSpotWatch.com

http://NW7US.us

No, this is not the name of another royal baby… it’s about my third attempt to build a 2m antenna for my SOTA activations. In my earlier iterations I was unable to strike the balance between size/weight and usability.

What happened so far:

My first attempt to build a Yagi-Uda antenna was based on a design by  Paul/KD5IVP. It worked, but had some crucial flaws for my endeavors. It was a 3-element antenna made out of piano wire and a carbon fiber arrow as a boom. Very small and  lightweight indeed but in high winds/gusts the elements were flapping like a seagull during take-off. It’s demise came on it’s second outing… the arrow broke in half while bushwhacking up a mountain and I lost some of the piano wires in the woods. To read more about it and to see it in action check out this post.

I then moved on to a tape measure 3-element antenna based on a design by Joe/WB2HOL. It worked well and accompanied me on several activations –  even a few 14ers (Summits higher than 14’000 ft / 4267m). My main gripe with this antenna is that it is delicate to transport as well. The steel tape gets kinked easily since the antenna is strapped to the outside of my backpack. It’s rather easy to replace the director and reflector, but soldering the coax to the steel radiator is another story. It turned out that this design is also vulnerable to high winds and your arms start to feel the weight after a few minutes without support. You can see the antenna in action in this video, around 3:30 into the clip.

The one?
I continued my research for a suitable 2m Yagi-Uda which would fit my requirements:

• Lightweight (but sturdy enough to withstand high winds)
• Easy and save to transport
• Easy to build (even for me)

I eventually stumbled onto IZ2UUF’s Website –  an Italian radio amateur who enjoys hiking and playing with radios as well. He designed an 4-element Yagi-Uda weighing only 80 grams (~2.9 ounces)!! All elements fit into the fiberglass boom (fishing rod) for easy transport with no matching network necessary. The description to build the antenna focused on the critical parts with excellent pictures to support the instructions.

Davide/IZ2UUF modeled the antenna with 4NEC2, a free antenna modeling software package. Since he shared his input file with me, I took the opportunity to download the free SW and to learn more about antenna modelling. After a few more e-mail exchanges with him I was convinced by his design and started to source all the parts.

I did not have afiberglass fishing pole available and opted to use a plastic one I had lying around. Davide is using aluminum welding rods for his elements which I could not find at the desired length/diameter here in the US. I therefore ordered aluminum alloy 6061 rods instead (1/8″ x 6′ ) from a supplier in IL (for details see the resource section below). My build also differs in the connector (BNC instead SMA). All these changes resulted in a slightly heavier (194 g / 6.8 ounces) first version compared to Davide’s antenna. My boom alone is heavier than Davide’s complete antenna (96 g / 3.4 oz). However, I am planning to improve/reduce the weight in version two.

I had a chance to use the antenna over the week-end during the CO-14er event. All I can say so far is that it worked well and that the weight is not an issue at all… huge improvement to the tape-measure version.

For more pictures, a weight comparison and resources head over to my blog.

73, Matt/KØMOS
